Keeping a close watch, Vivotek
Vivotek offers multi-sensor dome network camera with 180-degree panoramic view
The MS9390-HV is the latest and most efficient panoramic network camera offered in surveillance. Through the use of two wide angle lenses, electronic image stitching and high- resolution sensors, the 8MP 180° MS9390-HV is in a new class all by itself. With its unique dual-sensor design, the MS9390-HV is able to maintain a higher vertical FOV than most traditional multi-sensor panoramic cameras using four sensors. This higher vertical FOV enables users to have more video coverage, thereby enabling them to capture more evidence below the point of camera installation.
The MS9390 -HV goes even further with WDR Pro technology for high contrast environments, 30 fps at full resolution, and 180° IR illuminators up to 20 meters, ensuring users with 24 x 7 comprehensive panoramic video surveillance. In addition to its panoramic image quality, the MS9390-HV is also simple to install. It has been designed to be directly wall-mounted, including 20° of internal tilt adjustment on the lenses to get the exact angle desired. With an IP66 weather-proof and IK10 vandal proof-housing, the MS9390-HV can be installed both indoors and outdoors, and handle most of what nature has to offer.
The only accessory available for MS9390-HV is a sunshield, which is included with the camera. To top it all off, the MS9390-HV utilizes H.265 compression and Smart Stream III technology. This combination enables users to greatly save on storage and bandwidth consumption usually associated with high- resolution surveillance. Electronic image stitching is best at 3~20 metres distances. A distance under 3 metres is too close to the camera, and seamless stitching is unlikely.
The key features are:
- 8-megapixel resolution
- H.265 compression technology
- 180° panoramic view
- 30 fps @ 4512 x 1728
- Video alignment for a seamless image
- Smart Stream III to optimize bandwidth efficiency
- Built-in IR illuminators, effective up to 20 meters
- SNV (supreme night visibility)
- 3D noise reduction for low-light conditions
- Built-in microphone
- Built-in microSD/SDHC/SDXC card slot
- Weather-proof IP66-rated and vandal-proof IK10-rated housing.
